Spectra Precision HL450 Laser Receiver

SKU: HL450
$343.00 $374.00
You Save: $31.00 9%
Checkout Secure
Need more info? Call us +61 8 9335 1718

Spectra Precision HL450 Laser Receiver

Superior alternative: Leica Rod Eye 160 (in stock)

Product overview

Highly versatile laser receiver for basic and advanced leveling and aligning applications

The Spectra Precision® HL450 Laserometer is an easy-to-use tool that accurately measures elevations across the site, and is ideal for use with any rotating transmitter.

The HL450 Laser Receiver features a digital readout of elevation that provides a numeric display of ± 40 mm or ±1.5 inches. The readout is displayed on the large front and rear LCD’s and shows exactly how far the elevation is from on-grade. Accurate measurements can be made without moving the rod clamp, saving time and increasing productivity.

The HL450 has a 102 mm (4 inches) reception height, double the typical industry standard, which allows quick acquisition of the laser beam. Also included is a patented anti-strobe sensor that prevents construction lights from setting off the receiver and makes it easier to identify the laser beam signals.

The Laserometer is designed to survive the tough construction site conditions. It is totally waterproof and can withstand a drop up to 1.5 meters (5 feet) onto concrete.



Features

  • Digital Readout of Elevation allows faster readings by displaying the exact numerical distance from grade, eliminating the need to move the receiver to get to "on-grade"
  • Anti-Strobe Sensor stops construction strobe lights from setting off the receiver and eliminates phantom strikes for easier identification of true laser beam signals
  • Large reception height allows faster readings by acquiring the beam quickly and makes it easier to stay in the beam
  • Durable in tough environments provides less downtime due to damage or service requirements after accidental drops



Includes:

  • HL450 receiver
  • C45 clamp
  • Universal Multi-language User Guide
  • 2 x AA batteries



Specifications

 Working Radius 1 m - 200 m (3 ft - 650 ft)
Laser Detection Height 102 mm (4“)
Numeric Readout Height 76 mm (3“)
Accuracy (Dead band) Fine 1.0 mm 0.05 in 1/16 in
Medium 5.0 mm 0.20 in 1/4 in
Calibration 0.1 mm 0.01 in 1/64 in
Reception Angle ± 45° minimum
Detectable Spectrum 610 nm ... 900 nm
Beeper Volumes Loud = 100+ dBA
Low = 65 dBA
Power Supply 2 x 1.5 Volt “AA” batteries
Battery Life 70+ hours
Automatic Shut Off 30 min
Environmental Waterproof, Dustproof to IP67
Weight without clamp 371 g (13.1 oz.)
Dimensions without clamp 168.0 x 76.0 x 36.0 mm (6.6” x 3.0” x 1.4”)
Operating Temperature -20°C...+60°C (-4°F... +140°F)
Storage Temperature -40°C...+70°C (-40°F...+158°F)


Need help choosing a Receiver? Read our Receiver Buying Guide or Contact us
