Topcon RL-HV1S Single Grade Rotating Laser (Rechargeable PREMIUM - LS100D Receiver)

SKU: 1051612-09
$2,476.00
Checkout Secure
Need more info? Call us +61 8 9335 1718

Topcon RL-HV1S Single Grade Rotating Laser (Rechargeable PREMIUM - LS100D Receiver)

The RL-HV1S single-grade laser from Topcon is built for ultimate durability, designed to be rugged and compact, allowing you to get twice the laser & Bluetooth pairing for a great price.

Designed for a wide variety of applications, it can be used for horizontal, sloping and vertical laser applications. Slopes up to ±15% can be used in the X axis. Turn it on its side and use it for layout and alignment applications.

The RL-HV1S excels in long range operation. Need to shoot elevations up to 400m from your laser? No problem! This instrument has the power and range to cover an 800m (diameter) jobsite as well as remote pairing and operation from your smart phone (Horizontal operation 100m, Vertical Operation 20m).

Premium HV1S kit includes the Topcon LS-100D Millimeter hand receiver as well as Rechargeable battery (up to 65hrs).

The RL-HV1S is “jobsite tough” and with its IP66 rating, the unit can withstand dust, a sudden shower and even torrential rainfall. Topcon stands behind this reliable and accurate laser with a 5-year warranty.

Specifications

  • Accuracy H: ±10 arc seconds
  • Self-Leveling Range: Horizontal/Vertical ±5°
  • Grade Single: ±15%
  • Working Area: 800m or more (diameter)
  • Rotation Speed: 300, 600 rpm (selectable)
  • Topcon Laser Manager App: Bluetooth 5.0
  • Range: Horizontal 100m/Vertical 20m
  • Battery Duration: 65hrs
  • Battery Charging: Approx. 13hrs
  • Operating Temp.: 20ºC to 50ºC
  • LS-100D Premium Hand Receiver: ±0.5, 1, 2, 5 & 10mm

Includes

  • Topcon RL-HV1S Single Grade Laser Level
  • Topcon LS-100D Premium Receiver (mm)
  • Topcon (Holder 110) Receiver Clamp
  • Rechargeable NIMH Battery (BT-79Q)
  • Battery Charger (AD-15E)
  • Carry Case
  • Operator Manual

*Tripod not included.
