Major Tech MT1882 1000V AC/DC IP67 True RMS Multimeter

SKU: MT1882
$160.00

Freight Charge for orders under $300 ex. GST / Free delivery for orders which exceed $300 ex. GST.

• If you require your order urgently, then you can choose express delivery - price TBC at point of sale.

You are most welcome to use your own courier if preferred and there is no admin fee for this.

Checkout Secure
Need more info? Call us +61 8 9335 1718
  • CAT IV 600V and CAT III 1000V
  • IP67 Dust & waterproof with O-ring sealed casing
  • Measures AC and DC voltage to 1000V
  • Variable Frequency Drive
  • Capacitance to 60mF
  • -20°C to 1000°C Temperature Measurement
  • Relative mode
  • Measures frequency range of 10Hz to 10MHz on electronic and electrical circuits
  • 6000 Count LCD display
  • 61 segment analogue bargraph
  • Non-contact voltage detector above 110V AC, LCD turns red
  • Blue back light for dimly lit areas
  • Auto range with manual override
  • MIN / MAX / Data hold
  • Full ranges protection & Auto power off
  • Overmould rubber housing & Integrated test lead holder

The MT1882 is a True RMS professional multimeter especially designed for everyday use by HVAC technicians and electricians, whist offering voltage measuring ranges up to 1000V AC and DC and with useful measuring ranges of Temperature, Resistance, AC/DC Current, Capacitance and Frequency. NCV function, automatic Non-Contact voltage detection, the LCD backlight will glow red when AC voltage above 110V is sensed. The large 6000 count backlit LCD display with a 61 segment bargraph ensures that readings are easy to read under all circumstances. The meter has been designed that should a user turn the rotary switch in any direction whilst and input of up to 1000V AC/DC is applied to the meter, the meter will not get damaged. The meter has a double moulded rubber case with IP67 waterproof and dustproof rating, rugged design for heavy duty use.

Specifications

Function Range Resolution Accuracy
DC Voltage 600mV – 1000V 1V ±(0.5% + 5 Digits)
AC Voltage 6V – 1000V 1V ±(0.8% + 4 Digits)
AC Voltage (VFD) 50V – 600V 0.1V ±(4.0% + 9 Digits)
DC Current 600uA – 10A 0.01A ±(1.0% + 3 Digits)
AC Current 600uA – 10A 0.01A ±(1.5% + 3 Digits)
Resistance 600Ω – 60MΩ 0.01MΩ ±(0.8% + 2 Digits)
Capacitance 60nF – 60mF 0.01mF ±(4.0% + 5 Digits)
Temperature -20°C – 1000°C 1°C ±(3.0% + 5°C Digits)
Frequency (Electronic) 9.999Hz – 10MHz 0.01MHz ±(1.0% + 5 Digits)
Frequency (Electrical) 10 ~ 1KHz 0.0Hz ±(1.5% reading)
Duty Cycle 0.1% – 99.9% 0.1% ±(1.2% + 2 Digits)
AC Response True RMS
Digital Display 6000 Count
Bargraph 61 Segmented
Continuity Test Audible signal if the resistance is approx. 50Ω or less
Diode Test Test current 0.9mA typical, open circuit voltage 3.2V DC typical
Non-Contact Voltage Detection above 110V AC, LCD display turns red
Data Hold Yes
Back Light Yes
Enclosure IP67 Dust & Waterproof Double Moulded
Battery 9V
Dimensions 187 x 81 x 50mm
Weight 342g



Safety Ratings



Includes:

  • Type K Temperature Probe
  • 9V Battery
  • MT810 Test Leads
  • Instruction Manual

Downloads

MT1882 Technical Datasheet MT1882 Instruction Manual

Shipping This Item Ships from Fremantle, Perth, Western Australia
Please allow 2 - 10 days for your order to arrive.

Although Most Stocked Products will generally Ship Overnight. We source products from all over the world to bring you epic offers and the lowest prices. This means sometimes you have to wait a little longer to get your order but it's always worth it!

Returns are easy.

simply contact us for a returns number and send your item to our returns centre for fast processing. We'll get you a replacement or refund in a snap!

Description

  • CAT IV 600V and CAT III 1000V
  • IP67 Dust & waterproof with O-ring sealed casing
  • Measures AC and DC voltage to 1000V
  • Variable Frequency Drive
  • Capacitance to 60mF
  • -20°C to 1000°C Temperature Measurement
  • Relative mode
  • Measures frequency range of 10Hz to 10MHz on electronic and electrical circuits
  • 6000 Count LCD display
  • 61 segment analogue bargraph
  • Non-contact voltage detector above 110V AC, LCD turns red
  • Blue back light for dimly lit areas
  • Auto range with manual override
  • MIN / MAX / Data hold
  • Full ranges protection & Auto power off
  • Overmould rubber housing & Integrated test lead holder

The MT1882 is a True RMS professional multimeter especially designed for everyday use by HVAC technicians and electricians, whist offering voltage measuring ranges up to 1000V AC and DC and with useful measuring ranges of Temperature, Resistance, AC/DC Current, Capacitance and Frequency. NCV function, automatic Non-Contact voltage detection, the LCD backlight will glow red when AC voltage above 110V is sensed. The large 6000 count backlit LCD display with a 61 segment bargraph ensures that readings are easy to read under all circumstances. The meter has been designed that should a user turn the rotary switch in any direction whilst and input of up to 1000V AC/DC is applied to the meter, the meter will not get damaged. The meter has a double moulded rubber case with IP67 waterproof and dustproof rating, rugged design for heavy duty use.

Specifications

Function Range Resolution Accuracy
DC Voltage 600mV – 1000V 1V ±(0.5% + 5 Digits)
AC Voltage 6V – 1000V 1V ±(0.8% + 4 Digits)
AC Voltage (VFD) 50V – 600V 0.1V ±(4.0% + 9 Digits)
DC Current 600uA – 10A 0.01A ±(1.0% + 3 Digits)
AC Current 600uA – 10A 0.01A ±(1.5% + 3 Digits)
Resistance 600Ω – 60MΩ 0.01MΩ ±(0.8% + 2 Digits)
Capacitance 60nF – 60mF 0.01mF ±(4.0% + 5 Digits)
Temperature -20°C – 1000°C 1°C ±(3.0% + 5°C Digits)
Frequency (Electronic) 9.999Hz – 10MHz 0.01MHz ±(1.0% + 5 Digits)
Frequency (Electrical) 10 ~ 1KHz 0.0Hz ±(1.5% reading)
Duty Cycle 0.1% – 99.9% 0.1% ±(1.2% + 2 Digits)
AC Response True RMS
Digital Display 6000 Count
Bargraph 61 Segmented
Continuity Test Audible signal if the resistance is approx. 50Ω or less
Diode Test Test current 0.9mA typical, open circuit voltage 3.2V DC typical
Non-Contact Voltage Detection above 110V AC, LCD display turns red
Data Hold Yes
Back Light Yes
Enclosure IP67 Dust & Waterproof Double Moulded
Battery 9V
Dimensions 187 x 81 x 50mm
Weight 342g



Safety Ratings



Includes:

  • Type K Temperature Probe
  • 9V Battery
  • MT810 Test Leads
  • Instruction Manual

Downloads

MT1882 Technical Datasheet MT1882 Instruction Manual
