Imex i88R H/V Red Rotating Laser Level with LRX10 Laser Receiver

SKU: 012-I88R
$1,158.00
Checkout Secure
Need more info? Call us +61 8 9335 1718

Imex i88R H/V Red Rotating Laser Level with LRX10 Laser Receiver

Product Overview

With self-levelling, grade slope function, scan mode, horizontal and vertical, remote controller and 9Ah lithium-ion mm Digital Detector battery the Imex range represents excellent value with versatile capabilities for a full range of construction functions. Combined with this are the highly visible heavy duty and robust, water and dust-proof case, with a fully enclosed laser diode for years of trouble-free use. A sensor based self-levelling system utilizing a level sensor and stepping motor gives excellent levelling ability and enhanced accuracy.

The simplified design elements and robust componentry also mean reduced calibration and service requirements. All backed by Imex warranty, service and innovative approach.





Features

  • Robust construction tough horizontal/vertical laser level.
  • Horizontal/Vertical self levelling (electronic). 600m range. Dual manual grade slope.
  • 9Ah lithium-ion battery – approx. 40 hours run time
  • USB quick charge port with car charger
  • LRX10 Digital Detector in mm reading (German made)
  • 90mm Detector reading the ultrafine, fine, medium, course and ultra course.
  • Scan Mode – Allows for part beam rotation in selected working environments, i.e. on interior walls, busy work-sites where other laser interference may be present. Various scan lengths and rotation placement.
  • Dual Grade – Grade slope to 5° (8.8%) in two directions, X and Y axis Simultaneously for true grade control. Ideal for pipe layout or concrete slab falls.
  • Plumb Spot – Top and bottom plumb spot beam to assist in setups over a point.
  • Accuracy – +/- 1.5mm @ 30 metres for excellent results every time.
  • Remote Control Panel – allows grade or other functions to be carried out up to 20 m away from the instrument, for true one-man operation and greater efficiency.
  • Hi-Visibility Case – unique Imex feature, easy to see on the busiest construction site, minimizes the risk of the unit being bumped, increasing safety and accuracy.

Includes

  • Laser Unit
  • LRX10 Detector
  • Remote control unit
  • USB cable
  • 9.0 Ah Lithium battery
  • Car charger
  • Target Plate
  • Hard carry case



Specifications

Self Levelling Range +/-5°
Working Distance 600m Diameter
Function Horizontal/Vertical
Scan Mode Yes, 0°, 10°, 45°, 90°, 180°
Slope Mode Yes – Dual manual grade to 5° 8.8%
Accuracy 1.5mm @ 30m
Rotation Speeds 0, 60, 120, 300, 600 rpm
Waterproof/Shockproof IP66
Light Source Red 635nm Class II
Power 9 Ah 3.7v lithium-ion
Detector LRX10 Double Sided
Working time – continuous use 40hrs approx Red
Charging Time 4 hours in a unit or removed from the unit
USBC Charging Yes; including 12v car charger
High Wind Sensitivity Re-set Yes
Remote Control Yes, iCR8
Weight – Unit Only 2.48kg
Detector – German Made LRX10 Double Sided
Detector – Pick Up 90mm -30mm to +60mm
Detector Reading Ultrafine – 0.5mm | Fine – 1.0mm | Medium – 2.0mm | Course – 5.0mm | Ultra Course – 10.0mm
Detector Power 1-AA > 50 hrs run

Download Brochure

Shipping This Item Ships from Fremantle, Perth, Western Australia
Please allow 2 - 10 days for your order to arrive.

Although Most Stocked Products will generally Ship Overnight. We source products from all over the world to bring you epic offers and the lowest prices. This means sometimes you have to wait a little longer to get your order but it's always worth it!

Returns are easy.

simply contact us for a returns number and send your item to our returns centre for fast processing. We'll get you a replacement or refund in a snap!

Description

Imex i88R H/V Red Rotating Laser Level with LRX10 Laser Receiver

Product Overview

With self-levelling, grade slope function, scan mode, horizontal and vertical, remote controller and 9Ah lithium-ion mm Digital Detector battery the Imex range represents excellent value with versatile capabilities for a full range of construction functions. Combined with this are the highly visible heavy duty and robust, water and dust-proof case, with a fully enclosed laser diode for years of trouble-free use. A sensor based self-levelling system utilizing a level sensor and stepping motor gives excellent levelling ability and enhanced accuracy.

The simplified design elements and robust componentry also mean reduced calibration and service requirements. All backed by Imex warranty, service and innovative approach.





Features

  • Robust construction tough horizontal/vertical laser level.
  • Horizontal/Vertical self levelling (electronic). 600m range. Dual manual grade slope.
  • 9Ah lithium-ion battery – approx. 40 hours run time
  • USB quick charge port with car charger
  • LRX10 Digital Detector in mm reading (German made)
  • 90mm Detector reading the ultrafine, fine, medium, course and ultra course.
  • Scan Mode – Allows for part beam rotation in selected working environments, i.e. on interior walls, busy work-sites where other laser interference may be present. Various scan lengths and rotation placement.
  • Dual Grade – Grade slope to 5° (8.8%) in two directions, X and Y axis Simultaneously for true grade control. Ideal for pipe layout or concrete slab falls.
  • Plumb Spot – Top and bottom plumb spot beam to assist in setups over a point.
  • Accuracy – +/- 1.5mm @ 30 metres for excellent results every time.
  • Remote Control Panel – allows grade or other functions to be carried out up to 20 m away from the instrument, for true one-man operation and greater efficiency.
  • Hi-Visibility Case – unique Imex feature, easy to see on the busiest construction site, minimizes the risk of the unit being bumped, increasing safety and accuracy.

Includes

  • Laser Unit
  • LRX10 Detector
  • Remote control unit
  • USB cable
  • 9.0 Ah Lithium battery
  • Car charger
  • Target Plate
  • Hard carry case



Specifications

Self Levelling Range +/-5°
Working Distance 600m Diameter
Function Horizontal/Vertical
Scan Mode Yes, 0°, 10°, 45°, 90°, 180°
Slope Mode Yes – Dual manual grade to 5° 8.8%
Accuracy 1.5mm @ 30m
Rotation Speeds 0, 60, 120, 300, 600 rpm
Waterproof/Shockproof IP66
Light Source Red 635nm Class II
Power 9 Ah 3.7v lithium-ion
Detector LRX10 Double Sided
Working time – continuous use 40hrs approx Red
Charging Time 4 hours in a unit or removed from the unit
USBC Charging Yes; including 12v car charger
High Wind Sensitivity Re-set Yes
Remote Control Yes, iCR8
Weight – Unit Only 2.48kg
Detector – German Made LRX10 Double Sided
Detector – Pick Up 90mm -30mm to +60mm
Detector Reading Ultrafine – 0.5mm | Fine – 1.0mm | Medium – 2.0mm | Course – 5.0mm | Ultra Course – 10.0mm
Detector Power 1-AA > 50 hrs run

Download Brochure
