GEO-Laser RL-79L Fully Automatic Rotating Laser with 1km range

SKU: 0001.705.1
$3,520.00
Checkout Secure
Need more info? Call us +61 8 9335 1718

GEO-Laser RL-79L Fully Automatic Rotating Laser with 1km range

PRODUCT OVERVIEW

The automatic rotary laser, type RL-78L/-79L, is an all-around laser for horizontal and vertical use capable of electronic self-levelling over 3 axes. It emits a stationary or rotating laser beam, which turns into a light plane.

FEATURES

  • Fully automatic
    Automatic levelling and cut-out in case of low battery or jerky movements.

  • Special laser beam quality
    Diode laser with visible laser beam, high-powered lens, high life expectancy and low power consumption.

  • Robust metal housing
    Plastic-coated, swept and filled with nitrogen, 100 % watertight.

  • Automatic fixing of the laser light plane
    By pressing a button automatic search and fixing of the laser light plane of the Y axis. The function is as simple as it is ingenious: The rotating laser beam is received by the locking receiver FE-53 and then automatically directed to the position fixed before. Deviations are detected and corrected immediately. Accuracy +/- 1 mm/100 m.

  • Automatic function can be switched off
    Therefore inclination adjustment by points of reference is possible.

  • Increased safety
    Control indicators with blinking warning system for levelling, operating status and low battery.

  • Lithium ion rechargeable battery
    Operation time to 28 hours with one charge. Rechargeable in max. 5 hours without having to take out the battery.

  • Manual rotor adjustment
    Easy operation for exact positioning of the laser beam, rotor fixing and plumbing down with bubble level in rotor head.

  • Checking and adjustment
    Simple, fast and accurate! In conjunction with the LE-72, the automatic adjustment of the horizontal light plane is comfortably possible. This offers more security and increases accuracy.

  • Reliable system accessories
    for the best possible operation.

  • Examples for use
    Track surveying/laying, facade construction, shelf mounting, plant construction, planting machine control, sheet pile ramming, shuttering, height transfer, lifting of buildings, road level.

Quality Guarantee

Our lasers are the result of decades of experience in the research, development, and production of construction lasers. The design, the materials used, as well as our rigorous quality assurance process are guarantors of high functionality and a long service life. All our devices are designed and manufactured exclusively in Germany and are renowned worldwide for their perfection in terms of handling, precision, robustness, and quality.

SPECIFICATIONS

Laser class 3R /< 5 mW
Laser Diode visible red 658 nm
Laser range to 400 m
Beam diameter at laser at laser 13 mm
Self-levelling range ± 5 %
Permissible deviation ± 5 mm/100 m
Operating time up to 28 hours
External power supply 11 V DC to 14 V DC with cable 0117.02
Undervoltage cut-out yes
Waterproof to 3.5 m
Temperature range - 10° C to + 50° C
Weight 3,4 kg
Guarantee 24 month
Rotor speed adjustable: 0, 100, 200, 300, 600, 800 RPM
Automatic function horizontal and vertical
Automatic function can be switched off yes, either one or both axes
Adjustment possible in the field without having to open the device
Locking automatic laser light plane up to 500 m with receiver FE-53




Download Brochure

Shipping This Item Ships from Fremantle, Perth, Western Australia
Please allow 2 - 10 days for your order to arrive.

Although Most Stocked Products will generally Ship Overnight. We source products from all over the world to bring you epic offers and the lowest prices. This means sometimes you have to wait a little longer to get your order but it's always worth it!

Returns are easy.

simply contact us for a returns number and send your item to our returns centre for fast processing. We'll get you a replacement or refund in a snap!

Description

GEO-Laser RL-79L Fully Automatic Rotating Laser with 1km range

PRODUCT OVERVIEW

The automatic rotary laser, type RL-78L/-79L, is an all-around laser for horizontal and vertical use capable of electronic self-levelling over 3 axes. It emits a stationary or rotating laser beam, which turns into a light plane.

FEATURES

  • Fully automatic
    Automatic levelling and cut-out in case of low battery or jerky movements.

  • Special laser beam quality
    Diode laser with visible laser beam, high-powered lens, high life expectancy and low power consumption.

  • Robust metal housing
    Plastic-coated, swept and filled with nitrogen, 100 % watertight.

  • Automatic fixing of the laser light plane
    By pressing a button automatic search and fixing of the laser light plane of the Y axis. The function is as simple as it is ingenious: The rotating laser beam is received by the locking receiver FE-53 and then automatically directed to the position fixed before. Deviations are detected and corrected immediately. Accuracy +/- 1 mm/100 m.

  • Automatic function can be switched off
    Therefore inclination adjustment by points of reference is possible.

  • Increased safety
    Control indicators with blinking warning system for levelling, operating status and low battery.

  • Lithium ion rechargeable battery
    Operation time to 28 hours with one charge. Rechargeable in max. 5 hours without having to take out the battery.

  • Manual rotor adjustment
    Easy operation for exact positioning of the laser beam, rotor fixing and plumbing down with bubble level in rotor head.

  • Checking and adjustment
    Simple, fast and accurate! In conjunction with the LE-72, the automatic adjustment of the horizontal light plane is comfortably possible. This offers more security and increases accuracy.

  • Reliable system accessories
    for the best possible operation.

  • Examples for use
    Track surveying/laying, facade construction, shelf mounting, plant construction, planting machine control, sheet pile ramming, shuttering, height transfer, lifting of buildings, road level.

Quality Guarantee

Our lasers are the result of decades of experience in the research, development, and production of construction lasers. The design, the materials used, as well as our rigorous quality assurance process are guarantors of high functionality and a long service life. All our devices are designed and manufactured exclusively in Germany and are renowned worldwide for their perfection in terms of handling, precision, robustness, and quality.

SPECIFICATIONS

Laser class 3R /< 5 mW
Laser Diode visible red 658 nm
Laser range to 400 m
Beam diameter at laser at laser 13 mm
Self-levelling range ± 5 %
Permissible deviation ± 5 mm/100 m
Operating time up to 28 hours
External power supply 11 V DC to 14 V DC with cable 0117.02
Undervoltage cut-out yes
Waterproof to 3.5 m
Temperature range - 10° C to + 50° C
Weight 3,4 kg
Guarantee 24 month
Rotor speed adjustable: 0, 100, 200, 300, 600, 800 RPM
Automatic function horizontal and vertical
Automatic function can be switched off yes, either one or both axes
Adjustment possible in the field without having to open the device
Locking automatic laser light plane up to 500 m with receiver FE-53
